Continuous 24/7 Recording Across Multiple Channels
4K HDMI and VGA Dual Video Outputs
Broad Compatibility with Reolink IP Cameras
RM1,399.00–RM2,779.00Price range: RM1,399.00 through RM2,779.00
Reolink RLN16
RLN16 Video
4 Videos
Others Video
Disclaimer: The videos are intended for reference purposes only and are not guaranteed to be 100% accurate. Please refer to the actual product or contact us for verification.
Channel Capacity, PoE System Overview & Hardware Architecture
What type of NVR is the Reolink RLN16 and how many camera channels does it support?
A: The Reolink RLN16 is a high-capacity Network Video Recorder equipped with 16 built-in Power over Ethernet (PoE) ports. It supports up to 24 IP cameras in total (With a maximum of 16 directly connected wired PoE cameras and additional cameras connected via your local network switch or router) for 24/7 continuous recording, multi-channel live monitoring, and centralized device management.
How does the built-in 16-channel PoE system work?
A: The rear panel features 16 independent RJ45 PoE ports conforming to IEEE 802.3af/at standards. Each port delivers up to 25W of power over standard Cat5e/Cat6/Cat7 Ethernet cables, transmitting both high-definition digital video and electric power simultaneously over a single cable up to 100 meters (330 feet) without requiring separate power adapters for each camera.
Can the RLN16 support Reolink WiFi cameras and battery-powered cameras?
A: Yes. In addition to direct wired PoE cameras, the RLN16 can record and manage Reolink WiFi cameras (Such as E1 series, TrackMix WiFi, RLC-843WA, and Video Doorbells) over your local WiFi router network. Certain newer Reolink battery-powered cameras with updated firmware can also link to the NVR for motion-triggered video recording and centralized live viewing.
Does the RLN16 feature physical front-panel navigation controls?
A: Yes. In addition to USB mouse operation, the front panel of the RLN16 chassis features a dedicated directional control panel (Up, down, left, right, and select buttons) alongside a front USB 2.0 port, Power LED, and HDD activity LED, allowing basic menu navigation directly from the chassis.
Can the RLN16 operate completely offline without an Internet connection?
A: Yes. The RLN16 can operate as an entirely offline, self-contained closed-circuit security system. You can connect PoE cameras directly to the 16 rear ports, record 24/7 footage to the installed internal SATA hard drives, and view live video feeds or playback on a connected HDMI or VGA monitor. Internet connectivity is only required if you wish to receive mobile push notifications, email alerts, or access camera streams remotely through the Reolink App and Client.
Video Decoding, Display Output & Audio
What video resolutions and stream decoding limits are supported?
A: The RLN16 supports ultra-high-definition decoding up to 16 Megapixels Ultra HD (7680x2160), 12MP (4096x3072 / 4512x2512), 4K 8MP (3840x2160), 5MP (2560x1920), 4MP (2560x1440), 3MP (2304x1296), 1080p Full HD, and 720p HD across both mainstream and substream profiles.
Which video compression codecs are supported by the NVR?
A: The system supports both advanced H.265 (HEVC) and standard H.264 video compression formats. This optimizes hard drive storage efficiency and conserves network bandwidth while preserving sharp detail and color accuracy in 4K and 16MP footage.
What monitor display outputs and output resolutions are available?
A: The rear panel provides two local display outputs:
HDMI Output: Supports display resolutions of 3840x2160 (4K UHD), 1920x1080 (1080p Full HD), 1280x1024, 1280x720, and 1024x768.
VGA Output: Supports display resolutions of 1920x1080 (1080p Full HD), 1280x1024, 1280x720, and 1024x768.
How many channels can be played back synchronously at the same time?
A: The RLN16 supports synchronous multi-channel playback of up to 4 camera channels simultaneously on a locally connected HDMI/VGA monitor or via the Reolink Client desktop software, allowing you to review synchronized incident footage from multiple angles.
Does the RLN16 support audio recording and local audio output?
A: Yes. The NVR records incoming audio streams from connected cameras equipped with integrated microphones. For local audio monitoring on an external amplified speaker or TV, the rear panel includes 1 RCA audio output port. Two-way interactive talk can also be conducted using the Reolink App or Client software.
Hard Drive Installation, Storage Capacity & Recording Modes
Does this standalone RLN16 come with a hard drive, and what is the maximum storage capacity?
A: In this standalone edition, internal hard drives are sold separately (No HDD is pre-installed). The RLN16 features 2 internal SATA interfaces, supporting two 3.5-inch or 2.5-inch internal SATA hard drives with a maximum capacity of 8TB per drive, providing a maximum total storage capacity of up to 16TB. Dedicated surveillance-grade drives (Such as Western Digital Purple or Seagate SkyHawk) are recommended for continuous write performance.
How do you install internal SATA hard drives into the RLN16 chassis?
A:
Ensure the NVR power switch is set to "Off" and unplug the power adapter.
Unscrew the screws securing the metal top cover and slide the cover off.
Connect the SATA data cables and power cables from the NVR motherboard to your SATA hard drive(s).
Position the hard drive(s) on the bottom chassis tray and tighten the mounting screws from underneath.
Reassemble the outer casing, reconnect power, turn on the power switch, navigate to Settings > Storage on the monitor, and format the newly installed drive(s).
Does the RLN16 support external eSATA hard drives?
A: No. Current hardware revisions (Such as N6MB01) do not include an external eSATA port. All storage expansion must be accommodated internally using the two onboard SATA interfaces (Up to 2x 8TB = 16TB total).
What recording modes and schedules can be configured?
A: Each channel can be configured independently with three flexible recording modes:
24/7 Continuous Recording: Uninterrupted around-the-clock recording across selected channels.
Motion / Smart AI Event Recording: Records video only when person, vehicle, animal, or general motion triggers occur.
Scheduled / Timer Recording: Records only during specific hours or days designated by the user.
What happens when the hard drive reaches full capacity?
A: By default, the RLN16 has automatic HDD Overwrite enabled. When storage reaches full capacity, the NVR automatically writes over the oldest recorded footage to make room for new video streams without manual file deletion or surveillance interruption.
Physical Ports, Power Specs & Hardware Reset
What physical ports and indicators are located on the RLN16?
A:
Front Panel: Directional Control Panel, Power LED, HDD Activity LED, and 1x USB 2.0 port.
Rear Panel: Power On/Off rocker switch, 1x DC 48V-54V Power Input Port, 1x RCA Audio Output Port, 1x USB 2.0 port, 1x HDMI Port, 1x VGA Port, 1x RJ45 LAN/WAN Gigabit Uplink Port, and 16x RJ45 PoE IP Camera Ports.
What are the power requirements and power consumption of the RLN16?
A: The NVR is powered by an included external DC 48V to 54V power supply. The base power consumption of the NVR unit is under 10W (Excluding connected hard drives and PoE power output delivered to cameras).
What are the physical dimensions, weight, and operating temperature range?
A:
Dimensions: 330 mm (Width) x 45 mm (Height) x 285 mm (Depth) (1U rack-mountable profile)
Weight: Approximately 2.4 kg (Chassis without installed HDDs)
Operating Temperature: -10 degrees Celsius to +45 degrees Celsius (14 degrees Fahrenheit to 113 degrees Fahrenheit)
Operating Humidity: 10% to 90% non-condensing
How do you back up or export video recordings locally?
A: Plug a FAT32 or NTFS formatted USB flash drive into the front or rear USB 2.0 port. Using the connected mouse and monitor interface, navigate to the Playback menu, select your camera channel and time range, click the Backup/Download icon, and export the selected clips as MP4 video files.
How do you perform a factory reset on the RLN16?
A: You can restore factory defaults through the monitor interface under Settings > System > Maintenance > Restore Defaults. Alternatively, if locked out, power off the unit, open the chassis, press and hold the internal reset button located on the motherboard while powering on the unit, and hold for 10 seconds until the system reboots.
Camera Pairing, PoE Wiring & Multi-Channel Management
How do you connect and configure wired PoE cameras to the RLN16?
A:
Connect an Ethernet cable from the camera's RJ45 port directly into one of the 16 PoE ports on the rear of the NVR.
The NVR automatically supplies power and negotiates an internal private IP address for the camera.
On your connected monitor, go to Settings > Channel > Channel Management and ensure Auto Add is enabled. The video feed will appear on the live preview screen within seconds.
Which Reolink camera models are compatible with the RLN16?
A: The RLN16 is compatible with the entire Reolink ecosystem, including 4K/12MP/16MP PoE models (Such as RLC-843A, RLC-833A, RLC-823S2, Duo series, TrackMix series), Reolink WiFi cameras, and Reolink PoE/WiFi Video Doorbells.
How do dual-lens cameras consume channels on the RLN16?
A: Reolink Duo cameras stitch dual sensors internally into a single panoramic video stream and consume only 1 NVR channel. Reolink TrackMix cameras transmit both a wide-angle and a telephoto tracking stream, occupying 2 NVR channels.
Does the RLN16 support third-party ONVIF cameras?
A: Yes. The RLN16 supports standard ONVIF Profile S/T/G third-party IP cameras connected over the local area network. However, proprietary features such as advanced AI detection categorization, two-way audio talk, siren triggers, and spotlight illumination controls are only guaranteed on native Reolink cameras.
Can PoE cameras connected to the NVR be accessed individually on the local network?
A: Cameras connected directly to the NVR's 16 PoE ports operate on an isolated internal subnet managed exclusively by the NVR. To access their standalone web interfaces or RTSP streams directly from your PC, you can enable the "Virtual Host" feature in the NVR's network settings.
How do you set up remote mobile access using the Reolink App?
A:
Connect the NVR's LAN/WAN port to your home or office internet router using an Ethernet cable.
Open the Reolink App on your smartphone, tap the "+" icon in the top right corner, and scan the QR code located on the NVR chassis label or select Input UID/IP and type the 16-character UID.
Enter the administrator username and password created during initial setup wizard initialization.
Tap "Access" to view all connected camera channels remotely over cellular data or external WiFi.
Which client operating systems and desktop browsers are supported?
A:
Desktop Software: Reolink Client software for Windows PC and macOS.
Mobile Apps: Reolink App for iOS (iPhone/iPad) and Android smartphones/tablets.
Web Browsers: Direct browser access via Microsoft Edge, Google Chrome, Mozilla Firefox, and Apple Safari.
How many user accounts and simultaneous video streams does the RLN16 support?
A: The NVR supports up to 20 configured user accounts (1 administrator account and 19 standard user accounts) and up to 12 simultaneous remote video streams (2 mainstreams and 10 substreams).
What networking protocols and security standards are supported?
A: The RLN16 supports standard networking protocols including HTTPS, SSL/TLS, TCP/IP, UDP, HTTP, IPv4, DHCP, UPnP, RTSP, RTMP, SMTP, NTP, DNS, DDNS, FTP, and Reolink P2P cloud relay.
What items are included in the standard retail package of the standalone RLN16?
