Smart 4K Professional PoE Bullet with 5x Optical Zoom
4K 8MP Ultra HD Resolution for Clarity
5× Optical Zoom for Detailed Close-Ups
Super-Wide 133° Diagonal Field of View
Smart Person, Vehicle, and Animal Detection
Color Night Vision with Built-In Spotlights
Power Over Ethernet for Easy Wired Setup
RM1,299.00–RM2,049.00Price range: RM1,299.00 through RM2,049.00
Reolink RP-PCB8MZ
RP-PCB8MZ Video
7 Videos
Professional Series Video
Others Video
Disclaimer: The videos are intended for reference purposes only and are not guaranteed to be 100% accurate. Please refer to the actual product or contact us for verification.
4K Ultra HD Video, 5X Optical Zoom & AI-ISP Performance
What video resolution and frame rate does the Reolink RP-PCB8MZ deliver?
A: The Reolink RP-PCB8MZ delivers 4K Ultra HD video at 3840x2160 resolution (8 Megapixels) at a smooth 30 frames per second (fps). The mainstream frame rate can be configured between 2 fps and 30 fps (Default is 30 fps), while the substream runs between 4 fps and 15 fps (Default is 10 fps).
What type of optical zoom lens does the camera feature?
A: The camera is equipped with a 1/2.8-inch CMOS image sensor and a motorized 5X optical varifocal zoom lens with a focal length of f = 2.7 mm to 13.5 mm and a maximum aperture of F1.6. This enables you to zoom in on license plates, faces, or distant targets with optical clarity without degrading the 4K resolution.
What is the Field of View (FOV) across the 5X optical zoom range?
A: Due to the motorized 5X optical zoom varifocal lens, the field of view adjusts as follows:
Horizontal FOV: 108.6 degrees (Wide angle) to 32 degrees (Telephoto)
Vertical FOV: 56.2 degrees (Wide angle) to 18 degrees (Telephoto)
Diagonal FOV: 133 degrees (Wide angle) to 36.7 degrees (Telephoto)
What is AI-ISP and WDR technology on this camera?
A: AI-ISP (Artificial Intelligence Image Signal Processing) is an on-device algorithm that analyzes scenes in real time to optimize brightness, sharpen textures, and eliminate digital noise in low-light environments. Paired with true WDR (Wide Dynamic Range), it prevents washed-out highlights and underexposed shadows in challenging, high-contrast lighting conditions.
Which video compression codecs and bitrates are supported?
A: The camera supports dual video compression standards: advanced H.265 (HEVC) and standard H.264. The mainstream bitrate is adjustable from 2048 Kbps to 9216 Kbps (Default is 7168 Kbps), while the substream bitrate ranges from 64 Kbps to 512 Kbps (Default is 512 Kbps).
Night Vision, Spotlights & Active Deterrence
How far does the infrared (IR) night vision reach on the RP-PCB8MZ?
A: The camera provides black-and-white infrared night vision up to 30 meters (100 feet). It utilizes 4 high-efficiency 850nm IR LEDs paired with an automatic IR-cut filter that transitions smoothly between day and night modes based on ambient light levels.
What are the specifications of the built-in spotlights?
A: The camera features 4 integrated high-output spotlight LEDs producing 600 lumens of light at a 4000K warm white color temperature. When illuminated in low-light environments, they allow the camera to capture full-color night vision with natural color reproduction.
What lighting modes are available for the spotlights?
A: You can configure the spotlights into three distinct operating modes through the Reolink App or Client:
Always On: Automatically turns on at dusk and remains illuminated throughout the night.
Alarm-Triggered: Remains off during standby (Relying on covert IR night vision) and illuminates or flashes only when a target or perimeter breach is detected.
Manually Off: Disables the spotlights completely, allowing the camera to operate exclusively in black-and-white infrared night vision mode.
Does the RP-PCB8MZ support two-way audio communication?
A: Yes. The camera features an integrated noise-reducing microphone and a built-in high-output speaker. This enables real-time interactive two-way voice conversations with visitors, delivery couriers, or potential trespassers directly through the Reolink App or Client software.
Can the camera sound an audible siren automatically during an intrusion?
A: Yes. In addition to triggering the 600-lumen spotlights, the camera's built-in speaker can broadcast a loud siren alarm or a custom recorded voice warning automatically when an AI detection or perimeter rule is triggered, deterring trespassers before an incident occurs.
Edge AI Detection, Video Search & Perimeter Protection
What smart target classification capabilities are built into the RP-PCB8MZ?
A: The RP-PCB8MZ features on-device edge AI algorithms capable of recognizing and distinguishing between:
A: AI Video Search enables natural language querying to quickly locate specific video clips without manually scanning hours of recorded footage. Users can search descriptive terms such as "a woman wearing a yellow t-shirt" or "vehicles." When paired with a Reolink Professional Series NVR, it offers advanced search filters, quick shortcuts, and search history tracking.
What advanced Perimeter Protection analytics are supported?
A: The RP-PCB8MZ incorporates commercial-grade perimeter security analytics, including:
Line Crossing Alert: Triggers an alarm when a target crosses a virtual line drawn across a driveway, fence line, or entry gate.
Zone Intrusion Alert: Detects when a target enters a designated restricted perimeter zone.
Zone Loitering Alert: Flags an alert when a target lingers within a defined zone past a user-configured duration threshold.
What abnormal smart event detection features are available on this model?
A: The camera includes beta smart event detection algorithms that recognize:
Forgotten Object Detection: Alerts when an unattended package, bag, or object is left behind in a monitored zone.
Object Removal Detection: Flags an alert when an established object (Such as inventory, tools, equipment, or vehicles) is moved or removed from a designated area.
Can detection sensitivity, target size filters, and alarm delays be customized?
A: Yes. For person, motor vehicle, non-motorized vehicle, animal, and package detection, you can customize minimum and maximum object size filters, adjust numerical sensitivity levels (1 to 100), and configure alarm delay times to prevent momentary false triggers.
Hardware Alarm In/Out, Power Specs & Network Protocols
What are the specifications and functions of the Alarm In/Out interface?
A: The RP-PCB8MZ is equipped with a dedicated physical Alarm In/Out terminal connector on its tail cable:
1 Alarm Input Port: Supports up to 12V 1A to connect third-party physical sensors (Such as external PIR motion sensors, magnetic door/window contacts, or photoelectric beam detectors).
1 Alarm Output Port: Supports up to 12V 500mA to trigger external devices (Such as high-decibel auxiliary sirens, strobe lights, or access control relays).
How is the Reolink RP-PCB8MZ powered?
A: The camera supports two power methods:
Power over Ethernet (PoE): Conforms to IEEE 802.3af standard (48V active PoE via standard Cat5e, Cat6, or Cat7 Ethernet cable).
DC Power Adapter: Powered via an external DC 12.0V 2A power supply (Total power consumption is under 15W).
What connectors are located on the camera's pigtail tail cable?
A: The tail cable includes four connectors:
RJ45 10M/100Mbps Ethernet PoE Port (With outdoor waterproof screw lid)
DC 12V Power Input Port (With attached rubber weather cap)
Which network protocols and standards are supported?
A: The camera supports standard networking protocols: HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P, and standard ONVIF.
How many user accounts and simultaneous video streams does the camera support?
A: The RP-PCB8MZ supports up to 20 user accounts (1 administrator account and 19 general user accounts) and up to 12 simultaneous live video streams (2 mainstreams and 10 substreams).
Storage Options, App Setup & Software Integration
What storage options are available for recorded video footage?
A: The camera supports three primary storage destinations:
Local MicroSD Card: Installed directly into the camera's onboard waterproof card slot.
Reolink NVR: Centrally records multiple channels 24/7 over the local network or PoE switch.
Remote FTP / NAS Server: Automatically uploads motion clips or continuous video feeds over the network.
What is the maximum MicroSD card capacity supported, and where is the slot located?
A: The camera supports MicroSD cards up to 512GB (FAT32/exFAT format, Class 10 or higher recommended). The MicroSD card slot is located on the underside of the camera body beneath a sealed, weather-resistant metal hatch secured by screws.
How do you initially set up the camera using the Reolink App?
A:
Connect the camera to your router's LAN port, PoE switch, or Reolink NVR using an Ethernet cable and supply power.
Open the Reolink App on your smartphone, tap the "+" button in the top right corner, and scan the QR code located on the camera body or enter the 16-character UID manually.
Create a secure administrator login password and assign a name to your camera.
Once initialization finishes, live viewing, 5X optical zoom, and smart event configuration are immediately accessible.
Which desktop operating systems and web browsers are compatible?
A:
Desktop Software: Reolink Client software for Windows PC and macOS.
Mobile OS: Reolink App for iOS (iPhone/iPad) and Android devices.
Web Browsers: Direct web interface access via Google Chrome, Microsoft Edge, Mozilla Firefox, and Apple Safari.
Can the camera operate standalone without an NVR or Internet connection?
A: Yes. The RP-PCB8MZ functions standalone when powered by a PoE switch/injector or 12V DC adapter, recording motion events or continuous video directly to an installed MicroSD card. An Internet connection is only required for remote mobile access, push notifications, and initial cloud registration.
What are the physical dimensions, weight, and form factor of the RP-PCB8MZ?
A:
Form Factor: Bullet security camera with integrated 3-axis mounting bracket
Dimensions: 76 mm (Width) x 74 mm (Height) x 220 mm (Length / Depth including mounting bracket)
Weight: Approximately 776 grams (Camera unit without accessories)
Construction: Sturdy all-metal aluminum housing
What is the weatherproof rating and working temperature range?
A:
Weatherproof Rating: IP67 certified dust-tight and waterproof, engineered for outdoor exposure to rain, snow, and dirt.
Operating Temperature: -30 degrees Celsius to +55 degrees Celsius (-22 degrees Fahrenheit to 131 degrees Fahrenheit).
Operating Humidity: 10% to 90% non-condensing.
How do you mount and aim the camera on a wall or ceiling?
A:
Place the mounting hole template on the wall or ceiling, drill three pilot holes, and insert drywall anchors if needed.
Route the pigtail cable through the cable notch on the mount base and secure the base firmly with the supplied screws.
Loosen the adjustment knob on the bracket arm to pan, tilt, and rotate the camera toward your surveillance target.
Tighten the adjustment knob firmly to lock the camera into position.
Where is the hardware reset button located, and how do you restore factory defaults?
A: The hardware reset button is located on the pigtail tail cable under a protective cap. While the camera is powered on, press and hold the reset button for approximately 10 seconds until the camera beeps or restarts, restoring factory default settings.
What items are included in the standard retail package, and what is the warranty coverage?
A: Package Contents:
Reolink Professional Series RP-PCB8MZ Bullet Camera
1-Meter Ethernet Network Cable
Mounting Hole Template
Pack of Mounting Screws
Drywall Anchors
Waterproof RJ45 Cable Connector Lid
24-Hour Video Surveillance Warning Sign / Sticker
Multi-Language Operational Instructions
Quick Start Guide
A: Warranty:
Covered by Reolink's 3-year limited warranty for the Professional Series.
