Reolink W430

Smart 4K 8MP Wi-Fi 6 Camera with 5x Optical Zoom & Color Night Vision

4K 8MP Ultra HD Resolution for Clarity
5× Optical Zoom for Detailed Close-Ups
Dual-Band WiFi 6 for Stable Connection
Color Night Vision with Built-In Spotlights
Smart Person, Vehicle, and Animal Detection
IP67 Weatherproof Robust Aluminum Housing

Price range: RM749.00 through RM1,499.00

Addons

Storage

Clear

Reolink W430

W430 Video

4 Videos

Others Video

Disclaimer: The videos are intended for reference purposes only and are not guaranteed to be 100% accurate. Please refer to the actual product or contact us for verification.

Check it Out

4K UHD Video, 5× Optical Zoom & Optics

What video resolution and frame rate does the Reolink W430 deliver?

A: The Reolink W430 delivers 4K Ultra HD video at 3840x2160 resolution (8 Megapixels) at up to 15 frames per second (fps). Powered by an advanced 1/2.8-inch CMOS image sensor, it captures four times the clarity of traditional 1080p Full HD security cameras, allowing license plates, human faces, and distant objects to be recognized with precision.

What type of optical zoom lens does the W430 feature?

A: The camera is equipped with a motorized 5× optical varifocal zoom lens with fast autofocus. It allows you to zoom in on distant objects to examine hard-to-see details without any loss of 4K image quality, or zoom out to oversee a wide coverage area.

What is the Field of View (FOV) across the 5× optical zoom range?

A: Because of the motorized 5× optical varifocal lens, the field of view adjusts smoothly across the zoom range:

Which video compression codecs does the W430 utilize?

A: The camera utilizes high-efficiency H.265 (HEVC) video compression (with H.264 legacy support). H.265 significantly reduces network streaming bandwidth and storage consumption while preserving sharp details and vibrant color accuracy in 4K surveillance footage.

Does the Reolink W430 feature motorized pan and tilt (PTZ)?

A: No. The W430 features motorized 5× optical zoom and autofocus, but mechanical panning and tilting are not motorized. Viewing angles are adjusted manually during installation using the integrated 3-axis mounting bracket (which rotates 360 degrees and tilts 90 degrees), while digital zoom can also be used via the Reolink App or Client.

Night Vision, 5 Spotlights & Two-Way Audio

How far does the infrared (IR) night vision reach on the W430?

A: The camera provides black-and-white infrared night vision up to 30 meters (100 feet) in absolute darkness. It utilizes 4 high-efficiency 850nm IR LEDs (3W total consumption) paired with an automatic IR-cut filter that engages seamlessly when ambient illumination drops.

What are the specifications of the built-in spotlights and color night vision?

A: The W430 is equipped with 5 integrated high-output spotlights consuming 4W of power and producing a daylight color temperature of 6500K. When the spotlights illuminate in dark conditions, they light up the environment to capture full-color night vision.

What lighting modes are available for the 5 spotlights?

A: Through the Reolink App or Client software, you can configure three spotlight lighting modes:

Alarm-Triggered (Auto): Spotlights remain off during standby (relying on covert IR night vision) and illuminate or flash automatically only when an AI-classified target is detected.
Always On: Spotlights automatically activate at dusk and stay illuminated throughout the night.
Manually Off: Disables the spotlights completely, keeping the camera strictly in covert infrared black-and-white mode.

Does the Reolink W430 support two-way interactive audio?

A: Yes. The camera features an integrated noise-reducing microphone and a high-output built-in loudspeaker. This enables real-time, full-duplex two-way voice conversations with visitors, couriers, or trespassers directly through the Reolink App or Client software.

Can the spotlights and siren activate automatically upon detection?

A: Yes. You can configure the built-in 5 spotlights and the internal audio siren alarm (or custom voice recordings) to trigger automatically upon detecting a person, vehicle, or animal, creating an active deterrence barrier to warn off intruders before an incident occurs.

Dual-Band WiFi 6, Network Connectivity & Setup

What WiFi standards and frequency bands does the W430 support?

A: The W430 supports next-generation dual-band WiFi 6 technology conforming to IEEE 802.11 a/b/g/n/ac/ax across both 2.4 GHz and 5 GHz frequency bands:

What wireless security encryption standards are supported?

A: The camera supports standard WPA-PSK and WPA2-PSK encryption, as well as the latest WPA3 wireless encryption standard, ensuring your surveillance video feeds are safeguarded against unauthorized network interception.

Does the camera have an RJ45 Ethernet port for wired connectivity?

A: Yes. In addition to dual-band WiFi 6, the camera includes an RJ45 10M/100Mbps Ethernet port on its tail cable. It comes supplied with an outdoor waterproof connector lid to seal the cable joint against rain, snow, and moisture penetration.

How do you perform the initial setup using the Reolink App?

A:

Connect the camera to your router's LAN port using an Ethernet cable and power it on using the included DC 12V power adapter.
Open the Reolink App on your smartphone, tap the "+" icon in the top right corner, and scan the QR code located on the camera label (or select "Input UID/IP" to manually type the 16-character UID).
Create a secure administrator login password and assign a name to your camera.
Select your WiFi network (SSID), enter your WiFi password, and tap Save to store the wireless configuration.
Once verified, unplug the Ethernet cable; the camera will automatically reconnect and stream over WiFi.

How many simultaneous live streams and user accounts are supported?

A: The W430 supports up to 20 configured user accounts (1 administrator account and 19 general user accounts) and up to 12 simultaneous live video streams (2 mainstreams and 10 substreams).

Smart AI Detection, Deterrence & Recording Modes

What smart AI detection capabilities are built into the W430?

A: Powered by on-device edge neural processing algorithms, the W430 detects and distinguishes between:

What recording modes can be configured on the camera?

A: Because the W430 connects to constant DC mains power, it supports three versatile recording modes:

Motion / AI-Triggered Event Recording (default): Records video clips only when motion or classified target events occur.
24/7 Continuous Recording: Uninterrupted round-the-clock recording across day and night.
Scheduled / Timer Recording: Records only during specific hours or days of the week designated by the user.

Does the Reolink W430 support Time-Lapse video creation?

A: Yes. The W430 includes built-in Time-Lapse video capability, allowing you to compress long-term events—such as construction milestones, garden growth, sunrises, or weather changes—into short, dynamic video clips via the Reolink App or Client software.

Can custom Motion Detection Zones and Privacy Masks be configured?

A: Yes. Through the Reolink App or Client, you can draw customized Motion Detection Zones to exclude busy sidewalks or streets from triggering false alerts, and configure Privacy Masks to black out sensitive private views from live preview and recordings.

What alert notifications occur when motion or an AI event is triggered?

A: When an alarm rule is triggered, the camera can execute multiple alert actions:

Continuous DC Power, Storage Options & Ecosystem Integration

How is the Reolink W430 powered, and does it support Power over Ethernet (PoE)?

A: The Reolink W430 is a wired plug-in DC security camera and does NOT run on batteries or solar power. It is powered via an external DC 12.0V / 1A power supply (total power consumption is under 12W). It is a dedicated WiFi camera and does NOT support Power over Ethernet (PoE). It must be powered using the included DC 12V adapter, though its RJ45 Ethernet port can be used for wired data transmission.

What is the maximum local MicroSD card capacity supported, and where is the slot located?

A: The camera supports onboard local storage via a MicroSD card slot accommodating cards up to 512GB (FAT32 or exFAT format, Class 10 or higher recommended). The MicroSD card slot is located on the underside of the camera body beneath a weather-sealed metal hatch secured by screws.

Can the W430 record to Reolink NVRs, Home Hub, or FTP/NAS servers?

A: Yes. The camera integrates across multiple centralized storage platforms:

Reolink NVRs: Connects to RLN8, RLN16, RLN36, or NVS12W (Wi-Fi 6 NVR) over the local network for centralized 24/7 recording.
Reolink Home Hub: Wirelessly archives encrypted video across local storage drives without monthly cloud subscription fees.
Remote FTP / NAS Server: Automatically uploads continuous video feeds or motion-triggered clips via standard FTP/FTPS protocols.

Can the W430 integrate with third-party software and smart platforms?

A: Yes. Thanks to native ONVIF and RTSP streaming support, the camera integrates smoothly with third-party VMS platforms and home automation systems such as Home Assistant, Blue Iris, Synology Surveillance Station, and QNAP. It also natively supports Google Assistant for casting live video feeds to compatible smart displays.

Can the camera operate standalone without an NVR or Internet connection?

A: Yes. The W430 can function completely standalone when powered by its DC 12V power adapter, recording motion events or continuous video directly to an installed MicroSD card. An Internet connection is only required for remote mobile access, push notifications, and initial cloud registration.

Hardware Build, IP67 Weatherproofing & Physical Installation

What is the weatherproof rating and working temperature range?

A:

What are the physical dimensions, weight, and housing construction of the W430?

A:

Dimensions: 80 mm (Width) x 72 mm (Height) x 238 mm (Length / Depth including mounting bracket)
Weight: Approximately 863 grams
Housing: Sturdy, industrial-grade metal-aluminum housing offering impact resistance and heat dissipation
Antennas: Dual external omnidirectional WiFi antennas designed for long-range wireless signal reception

How do you mount and aim the camera on a wall or ceiling?

A:

Place the mounting hole template on the wall or ceiling, drill pilot holes, and insert drywall anchors if needed.
Route the tail cable through the cable notch on the mount base and secure the base firmly with the supplied mounting screws.
Orient the dual external antennas vertically or horizontally for optimal wireless signal reception.
Loosen the adjustment knob on the bracket arm with the included wrench to pan, tilt, and rotate the camera toward your surveillance target.
Tighten the adjustment knob firmly with the wrench to lock the camera into position.

Where is the hardware reset button located, and how do you perform a factory reset?

A: The hardware reset button is located on the pigtail tail cable (with a weather cap). While the camera is powered on, press and hold the reset button for approximately 10 seconds until the camera beeps or restarts, restoring original factory default settings.

What items are included in the standard retail package, and what warranty coverage is provided?

A: Retail Package Contents:

Reolink W430 (RLC-811WA) Camera
DC 12V / 1A Power Adapter
4.5-Meter Power Extension Cable
1-Meter Ethernet Network Cable
Mounting Hole Template
Pack of Screws
Drywall Anchors
Hex Wrench
Waterproof RJ45 Cable Connector Lid
24-Hour Video Surveillance Warning Sticker
Quick Start Guide
Operational Instructions

A: Warranty:
