Smart 16MP Dual-Lens PoE Camera with 180° Panoramic View
16MP Ultra HD Resolution for Exceptional Clarity
180° Dual-Lens Seamless Panoramic Wide View
Motion Track Overlays Target Movement Path
Smart Person, Vehicle, and Animal Detection
Full-Color Night Vision with Motion Spotlights
Power Over Ethernet for Stable Wired Connection
RM1,099.00–RM1,849.00Price range: RM1,099.00 through RM1,849.00
Reolink Duo 3 PoE
Duo 3 PoE Video
8 Videos
Others Video
Disclaimer: The videos are intended for reference purposes only and are not guaranteed to be 100% accurate. Please refer to the actual product or contact us for verification.
A: The Reolink Duo 3 PoE is a dual-lens security camera that captures 16MP resolution footage and merges two separate video feeds into a single, seamless 180° panoramic view.
What is the video resolution and image sensor used in the Reolink Duo 3 PoE?
A: The camera features a 1/2.7" CMOS sensor that outputs 16MP Ultra HD video at a resolution of 7680x2160 at 20 frames per second.
How does the camera achieve its wide-angle viewing angle?
A: It utilizes dual lenses and Reolink's image stitching algorithms to combine two image captures into a continuous 180° horizontal and 55° vertical field of view.
Does the Reolink Duo 3 PoE support two-way audio?
A: Yes, the camera has a built-in microphone and speaker, enabling full two-way audio communication.
Which smart home voice platforms are compatible with this device?
A: The Reolink Duo 3 PoE supports integration with Google Assistant for hands-free voice control and viewing.
Power, Connectivity & Hardware Specifications
How can the Reolink Duo 3 PoE be powered?
A: The camera can be powered using Power over Ethernet (PoE) via IEEE 802.3af (48V active) over a single Ethernet cable, or via a DC 12.0V 2A power adapter (Consuming less than 12W).
What physical connection ports are on the camera's breakout cable?
A: The camera breakout cable features:
One 10M/100Mbps RJ45 Ethernet port
One DC power input port
A protective waterproof lid connection
What are the physical dimensions and weight of the camera?
A: The camera dimensions are 195 x 103 x 56 mm, and it weighs 680 grams.
What are the lens specifications of the Reolink Duo 3 PoE?
A: The camera is equipped with dual lenses featuring a focal length of f=2.8mm and an aperture of F1.6.
What operating temperatures and environmental conditions can the unit withstand?
A:
Operating temperature range: -10°C to +55°C (14°F to 131°F)
Operating humidity range: 10% to 90%
Weatherproof rating: IP67 dust and water resistance
Video Quality & Night Vision Capabilities
What video compression formats are supported?
A: The camera supports H.265 compression for the main stream and H.264 compression for the sub stream.
What night vision modes are available on the camera?
A: The Reolink Duo 3 PoE offers auto-switching infrared (Black and white) night vision and full-color night vision powered by its integrated spotlights.
What are the technical specifications of the camera's built-in lights?
A:
Infrared LEDs: 6 pieces / 20mil / 850nm wavelengths with night vision up to 30 meters
Spotlights: 8 pieces / 5W / 6500K color temperature / 560 Lumens
What frame rates does the camera output?
A:
Main Stream Frame Rate: Adjustable from 4fps to 20fps (default: 20fps)
Sub Stream Frame Rate: Adjustable from 4fps to 20fps (default: 20fps)
What are the default bitrates (Code rates) for video encoding?
A:
Main Stream Bitrate: 3072 to 10240 Kbps (Default: 8192 Kbps)
Sub Stream Bitrate: 256 to 2045 Kbps (Default: 1024 Kbps)
Smart Detection, Storage & Recording
What smart detection categories can the camera identify?
A: Onboard AI algorithms enable the camera to detect motion, people, vehicles, and animals.
What recording modes can be configured?
A:
Motion-triggered recording (Default)
Scheduled recording
24/7 continuous recording
What local storage options are available on the camera?
A: The camera includes an onboard slot that supports microSD cards up to 512GB.
What is the Motion Track feature on the Reolink Duo 3 PoE?
A: Motion Track automatically combines and overlays a target's movement path over time into a single panoramic image or clip to display track history without long playback files.
Does the Reolink Duo 3 PoE support time-lapse video capture?
A: Yes, the camera natively supports time-lapse recording functionality.
Software, Networking & Remote Access
Which operating systems and apps can manage the camera?
A:
Desktop Computers: Windows PC and Mac OS
Smartphones & Tablets: iOS and Android via the Reolink App
Which web browsers are compatible with the camera?
A: You can stream and manage settings using Microsoft Edge, Google Chrome, Mozilla Firefox, and Apple Safari.
How many users and streams can access the camera simultaneously?
A:
Supports up to 20 registered user accounts (1 admin account and 19 standard user accounts).
Supports up to 12 simultaneous streams (2 main streams and 10 sub streams).
What network protocols and standards are supported?
How do you set up the Reolink Duo 3 PoE on the Reolink App?
A:
Step 1: Connect the camera to power/network and open the Reolink App.
Step 2: Tap the "+" icon in the top right corner and scan the QR code on the back of the camera or select Input UID/IP and type the 16-digit UID manually.
Step 3: Create a login password for the camera.
Step 4: Give the device a custom name.
Step 5: Finish initialization to start live viewing.
Box Contents, Installation & Maintenance
What items are included in the box with the Reolink Duo 3 PoE?
A:
Reolink Duo 3 PoE
1M Network Cable
Quick Start Guide
Surveillance Sticker
Mounting Plate
Pack of Screws
Mounting Hole Template
Waterproof Lid
How can the camera be mounted?
A: The camera can be installed on either a wall or a ceiling using the included mounting plate, screws, and security bracket.
Where are the physical microSD card slot and reset button located?
A: The microSD card slot and physical reset button are located on the underside panel of the camera body, protected behind a sealed rubber cover.
How do you adjust the camera's angle during installation?
A: Loosen the adjustment screw on the security mount, turn the camera to achieve the desired field of view, and re-tighten the screw to lock the camera into position.
What warranty is provided, and where can technical support be obtained?
A: The camera comes with a 2-year limited warranty. Official support resources and technical help are available at https://reolinkmalaysia.com.my/support.
