Smart 4K 8MP PoE Bullet Camera with 5x Optical Zoom & Spotlights
4K 8MP Ultra HD Resolution for Clarity
5× Optical Zoom for Detailed Close-Ups
Color Night Vision with Built-In Spotlights
Smart Person, Vehicle, and Animal Detection
Power Over Ethernet for Easy Wired Setup
Two-Way Audio with Built-In Security Siren
RM649.00–RM1,399.00Price range: RM649.00 through RM1,399.00
Reolink P430
P430 Video
4 Videos
Others Video
Disclaimer: The videos are intended for reference purposes only and are not guaranteed to be 100% accurate. Please refer to the actual product or contact us for verification.
What is the video resolution and sensor specification of the Reolink P430?
A: The Reolink P430 is equipped with a 1/2.8-inch CMOS image sensor delivering 4K 8-Megapixel Ultra HD resolution (Default 3840 x 2160 pixels at 25 frames per second). This ensures highly detailed video clarity for daytime and nighttime monitoring.
How does the optical zoom on the Reolink P430 work?
A: The P430 features a 5X optical zoom motorized lens (Focal length f=2.7mm to 13.5mm, aperture F=1.6 to 3.3). It allows you to zoom in on distant objects without compromising image quality or zoom out for a wider field of view (Horizontal: 105 degrees to 37 degrees, Vertical: 55 degrees to 17 degrees).
What night vision capabilities does the Reolink P430 feature?
A: The camera offers two night vision modes:
Infrared Night Vision: Powered by 4 IR LEDs (850nm) with an auto-switching IR-cut filter, providing clear black-and-white night vision up to 30 meters (100 feet).
Color Night Vision: Powered by 5 built-in spotlights (4W total, 6500K color temperature, 450 lumens) that illuminate the scene to deliver full-color video in total darkness.
What are the physical dimensions, weight, and exterior build of the camera?
A: The Reolink P430 features a heavy-duty metal aluminum housing. Its dimensions are 80mm x 72mm x 238mm (3.15" x 2.83" x 9.37"), and it weighs approximately 838 grams (1.85 lbs).
Is the Reolink P430 suitable for outdoor installation?
A: Yes. The camera possesses an IP67 weatherproof rating, making it completely dust-tight and resistant to heavy rain and snow. It operates reliably within temperatures ranging from -10 degrees Celsius to 55 degrees Celsius (14 degrees Fahrenheit to 131 degrees Fahrenheit) and relative humidity levels of 10% to 90%.
Power & Network Connectivity
How is the Reolink P430 powered?
A: The P430 offers flexible dual-power options:
Power over Ethernet (PoE): Powered via a single Ethernet cable (IEEE 802.3af standard, 48V active PoE).
DC Power Adapter: Can be powered using an optional DC 12.0V, 1A power adapter (power consumption is under 12W).
What type of network interface does the P430 use?
A: It uses a standard wired Ethernet connection via an RJ45 port supporting 10Mbps / 100Mbps data transfer speeds.
Does the Reolink P430 support WiFi connections?
A: No. The P430 is a dedicated PoE (Power over Ethernet) wired IP camera. For network communication and power transmission (When connected to a PoE switch/injector/NVR), a physical Ethernet cable is required.
What connectors are included on the camera’s pigtail cable?
A: The camera's tail cable includes three connection ports:
DC Power Port (For optional 12V power supply)
Hardware Reset Button (Protected by a cap)
RJ45 Ethernet Connector (Includes a waterproof lid assembly)
Can I use both PoE and DC power simultaneously?
A: You can plug in a DC power adapter while connected to a PoE switch as a backup, but only one power source is necessary. Power over Ethernet (PoE) is recommended for easier installation through a single cable.
Smart Detection & Alarm Features
What smart detection features are built into the Reolink P430?
A: The camera incorporates on-board AI analytics capable of distinguishing between people, vehicles, and pets from general motion. This hardware-level processing dramatically reduces false alarms triggered by moving trees, shadows, or insects.
Does the camera support two-way audio?
A: Yes. The P430 features a built-in microphone and speaker, enabling real-time two-way voice communication through the Reolink App or Client software.
Can the built-in spotlights serve as an active deterrent?
A: Yes. The 450-lumen spotlights can be configured to turn on automatically upon detecting a person, vehicle, or motion at night, illuminating the area and deterring potential intruders.
Does the Reolink P430 work with voice assistants?
A: Yes, the camera is compatible with Google Assistant, allowing you to view live video streams on supported smart displays using voice commands.
How are alerts delivered when motion or an event is detected?
A: Upon detecting motion or a specific target (Person/vehicle/pet), the P430 can instantly send push notifications to your smartphone, dispatch email alerts with photos or video clips, and trigger audio/light deterrents.
Storage & Recording Options
What local storage options are supported by the camera?
A: The camera features a built-in microSD card slot that supports cards up to 512GB for standalone local storage.
What recording modes are available on the Reolink P430?
A: The camera supports three recording modes:
Motion-Triggered Recording: Saves clips only when motion or smart events are detected (Default setting).
Scheduled Recording: Records during specific times configured in the app/client.
Continuous 24/7 Recording: Saves non-stop continuous footage to a microSD card, FTP server, or Reolink NVR.
What video compression format does the P430 use?
A: It utilizes high-efficiency H.265 video encoding, which reduces file sizes and bandwidth consumption while maintaining 4K video quality.
Can I record footage to a central network storage device or NVR?
A: Yes. The Reolink P430 supports recording to a Reolink Network Video Recorder (NVR), NAS systems, or off-site FTP servers over supported network protocols (RTSP, RTMP, FTP, ONVIF/P2P).
Approximately how many hours of footage can a 256GB card store?
A: Storage duration varies by bitrate settings (Mainstream default is 6144 Kbps). A 256GB microSD card typically holds approximately 24 to 48 hours of continuous 4K mainstream recording, or several weeks of motion-only event recording.
Setup, Installation & Mounting
What items are included in the standard Reolink P430 box?
A: The package includes:
Reolink P430 Camera
1-meter Network Cable
Quick Start Guide & Surveillance Sticker
Mounting Hole Template & Pack of Screws/Anchors
Waterproof Lid Kit
Hex Key (Wrench)
How do I initially set up the P430 using the Reolink App?
A:
Connect the camera to your router/PoE switch with an Ethernet cable.
Open the Reolink App and tap the plus (+) icon in the top right corner.
Scan the QR code on the camera body or tap "Input UID/IP" to manually enter the 16-character UID.
Create an admin password and name your device.
Save the configuration to finish initialization.
How do I mount the camera securely to a wall or ceiling?
A:
Use the mounting template to mark and drill holes in the desired wall or ceiling location.
Insert wall anchors (If mounting on drywall/masonry).
Secure the camera mount base using the supplied mounting screws, ensuring the cable passes through the base notch.
How do I adjust the camera's viewing angle after mounting?
A: Loosen the adjustment screw or knob on the bracket counterclockwise using the provided wrench. Rotate the camera body (Up to 360 degrees horizontally and 90 degrees vertically) to achieve your target field of view, then tighten the screw/knob clockwise to lock it in place.
How do I reset the camera to factory default settings?
A: Locate the hard reset button on the camera's pigtail cable. Press and hold the reset button for about 10 seconds while the camera is powered on until you hear a prompt or see the light indicators change, restoring all factory default settings.
Compatibility, Software & Access Control
Which platforms and web browsers support access to the Reolink P430?
A:
Desktop OS: Windows, Mac OS (via Reolink Client).
Mobile OS: iOS, Android (via Reolink App).
Web Browsers: Edge, Chrome, Firefox, and Safari.
How many simultaneous user accesses and video streams are supported?
A:
User Accounts: Up to 20 user accounts (1 administrator account and 19 user accounts).
Simultaneous Streams: Up to 12 simultaneous video streams (10 substreams and 2 mainstreams).
What network protocols and security standards does the P430 support?
A: It supports a wide range of protocols including HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, and P2P.
Is a monthly subscription required to use smart person/vehicle detection or app features?
A: No. All core camera features, including smart AI detection (Person, vehicle, pet), local storage recording, push notifications, two-way audio, and live streaming via the Reolink App/Client, are completely subscription-free.
What warranty and technical support are provided with the camera?
A: The Reolink P430 comes with a 2-year limited hardware warranty and official technical support accessible through the Reolink Help Center.
