Reolink P340

12MP PoE Security Camera with Motion Spotlight, Siren & AI Detection

12MP Ultra HD Resolution for Stunning Clarity
Color Night Vision with Built-In Spotlight
Smart Person, Vehicle, and Animal Detection
Power Over Ethernet for Easy Wired Setup
Two-Way Audio with Built-In Security Siren
Rugged IP67 Weatherproof Design for Outdoors

Price range: RM529.00 through RM1,279.00

Addons

Storage

Clear

Reolink P340

P340 Video

5 Videos

Others Video

Disclaimer: The videos are intended for reference purposes only and are not guaranteed to be 100% accurate. Please refer to the actual product or contact us for verification.

Check it Out

Overview, Core Specifications & Key Features

What is the Reolink P340 and what primary security functions does it serve?

A: The Reolink P340 is a 12MP Ultra HD outdoor Power over Ethernet (PoE) bullet security IP camera. Built with a heavy-duty aluminum metal housing and an IP67 weatherproof rating, it functions as a standalone or NVR-integrated security monitoring solution designed to capture high-definition video, distinguish human, vehicle, and pet targets, record two-way audio, and safeguard residential properties, garages, or commercial storefronts.

What is the form factor, casing durability, and weatherproof rating of the Reolink P340?

A:

Form Factor: Compact outdoor bullet security camera design with an adjustable 3-axis mounting bracket.
Housing Material: Heavy-duty aluminum alloy metal casing engineered for heat dissipation and outdoor physical protection.
Weatherproof Rating: Certified IP67 weather resistance against heavy rain downpours, snow, dust ingress, and severe outdoor elements.

What items are included in the package box when purchasing the Reolink P340?

A: The standard package includes:

Reolink P340 Security Camera
1 Meter Network Cable
Waterproof Lid for LAN Connection
Mounting Template
Pack of Mounting Screws and Wall Anchors
24/7 Surveillance Warning Sign / Sticker
Quick Start Guide / Operational Instructions

What are the physical dimensions and weight of the Reolink P340 camera?

A:

What warranty coverage and smart home platforms are supported by the camera?

A: The Reolink P340 includes a 2-year limited warranty valid when purchased through official Reolink stores or authorized resellers. It is compatible with Google Assistant, allowing live camera video streams to be displayed on smart display devices using simple voice commands.

12MP Ultra HD Optics, Field of View & Night Vision

What video resolution, frame rate, and video compression format does the Reolink P340 support?

A:

Resolution: 12MP Ultra HD (4512 x 2512 pixels at 20fps).
Frame Rate: Main stream operates from 2 fps up to 20 fps (Default: 20 fps); Sub stream operates from 4 fps up to 20 fps (Default: 10 fps).
Video Compression: Advanced H.265 video encoding format to optimize local network bandwidth usage and local drive storage.

What lens specifications and optical field of view does the camera provide?

A: The camera is built with a 1/2.49-inch CMOS image sensor and a fixed 4.0mm focal length lens featuring a large F1.6 aperture and an auto-switching IR-cut filter. It delivers a 93-degree horizontal field of view and a 49-degree vertical field of view for detailed area coverage.

What are the main stream and sub stream bitrate settings for the P340?

A:

How does the infrared night vision function and what is its maximum range?

A: For clear video monitoring in complete darkness, the camera features high-power 850nm IR LEDs (2pcs / 28mil) with an auto-switching IR-cut filter. The infrared night vision delivers crisp black-and-white video coverage at distances up to 30 meters (100 feet).

How does Color Night Vision function on the Reolink P340?

A: The camera features a built-in 6500K spotlight (1pc / 4.3W / 700 Lumens). When ambient light drops, the spotlight turns on automatically upon motion/AI detection or manually via the Reolink App to illuminate the surroundings in full color, capturing vivid nighttime video.

Smart AI Detections, Audio & Recording Modes

What smart AI detection capabilities are integrated into the Reolink P340?

A: Onboard AI image processing algorithms provide intelligent real-time target recognition and alert filtering for:

How does the onboard AI filtering help reduce false motion alarms?

A: By distinguishing the shape signatures of people, vehicles, and pets from general background movement, the camera filters out non-threatening motion triggers caused by swaying tree branches, falling leaves, rain, shadows, or flying insects, dramatically reducing unwanted alert notifications.

Does the Reolink P340 support Two-Way Audio and sound recording?

A: Yes. The camera features an integrated built-in microphone and a built-in speaker, enabling clear ambient audio recording as well as real-time two-way voice communication through the Reolink App or Client software.

What local video recording modes are supported on the P340?

A: Once a MicroSD card or NVR is connected, the P340 supports three primary recording modes:

What alert notification options are available when motion or AI targets are detected?

A: Upon target detection, the camera can trigger:

Power over Ethernet (PoE), Cabling & Network Setup

How is the Reolink P340 powered and does it support PoE?

A: The primary power method is active Power over Ethernet (PoE) adhering to IEEE 802.3af standards (48V Active), delivering electric power and high-speed network data over a single Ethernet cable. Alternatively, it can be powered using an optional DC 12V, 1A power adapter (Power consumption under 12W) connected to its tail cable DC jack. A DC power adapter is not included in the standard package box.

What Ethernet cables and PoE standards are required to operate the camera?

A: The camera uses standard Cat5e, Cat6, or higher unshielded or shielded twisted-pair Ethernet cables equipped with RJ45 connectors up to 100 meters (328 feet) in length. Power can be supplied via a standard 802.3af PoE switch, PoE injector, or Reolink PoE NVR.

Can the Reolink P340 be connected directly to a Reolink PoE NVR?

A: Yes. Plugging the Ethernet cable directly into an available PoE port on a Reolink NVR instantly provisions the camera for 24/7 continuous recording, active power delivery, and centralized management without complex network setup.

Which network protocols, operating systems, and web browsers are supported?

A:

Computer OS & Mobile Apps: Reolink App for iOS/Android; Reolink Client for Windows PC/Mac OS.
Web Browsers: Full live view, playback, and settings configuration via Microsoft Edge, Google Chrome, Mozilla Firefox, and Apple Safari.
Supported Protocols: HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, and P2P.

How many simultaneous user accounts and live video streams are supported?

A:

Hardware Layout, Local Storage & Mounting Options

What local MicroSD storage capacity is supported on the Reolink P340?

A: The camera features a built-in MicroSD card slot located on the underside of the metal housing beneath a weather-sealed panel, supporting microSD cards with storage capacities up to 512GB for local event or continuous video archiving.

Where are the physical connection ports, card slot, and reset button located?

A:

Is the Reolink P340 weatherproof and suitable for extreme outdoor environments?

A: Yes. The camera features a certified IP67 weatherproof rating, making it completely dust-tight and highly resistant to heavy rain downpours, snow, and severe environmental conditions.

What are the operational temperature and humidity limits for the camera?

A:

How do you adjust the camera bracket angle during installation?

A: Loosen the adjustment screw/ring on the mounting bracket arm counterclockwise using the provided hex key or by hand. Position the camera body toward your target monitoring area across 360-degree rotation and 90-degree tilt angles, then twist the adjustment screw back clockwise to fix the camera firmly in place.

Mobile App Setup, System Access & Troubleshooting

How do you perform initial setup for the Reolink P340 using the Reolink App?

A:

Connect the camera's RJ45 Ethernet cable to a PoE switch, PoE injector, or Reolink PoE NVR connected to your router.
Ensure your smartphone is connected to the same local WiFi router network.
Open the Reolink App and tap the "+" icon in the top right corner.
Scan the QR code located on the camera housing or tap "Input UID/IP" to manually enter the 16-character UID.
Follow the on-screen prompts to set an admin password, assign a device name, and tap "Finish" to complete setup.

How do you mount the Reolink P340 onto a wall or ceiling?

A:

Position the mounting template on your wall or ceiling surface and mark three screw holes.
Drill holes approximately 1 inch deep and insert plastic wall anchors if installing on drywall or masonry.
Thread the Ethernet tail cable through the wall or cable notch on the bracket base.
Fasten the mounting bracket to the surface using the provided screws, adjust the lens direction, and tighten the locking knob/screw.

How do you perform a factory default reset on the camera?

A: Locate the physical reset button assembly on the tail cable harness. While the camera is powered on, press and hold the reset button for 5 seconds until you hear an audio prompt or see status indicators flash, indicating factory default settings have been restored.

What should I do if the camera channel displays a "Video Loss" or connection error?

A:

Verify that your PoE switch, injector, or NVR port delivers active 48V IEEE 802.3af PoE power.
Check that the Ethernet cable connectors are firmly clicked into place on both ends.
Test the camera using another RJ45 Ethernet cable or plug it into a different PoE port.
Verify that your router's DHCP server assigned a valid IP address on the local network subnet.

What troubleshooting steps should I take if the live stream video feed is blurry or dark?

A:

Clean the glass lens cover with a soft microfiber cloth to remove dust, water spots, fingerprints, or cobwebs.
Ensure the protective plastic shipping film has been removed from the front camera face.
Check the Reolink App settings under Display > Day & Night to ensure the IR cut filter, spotlights, and night vision modes are set correctly.
