Reolink RLN8

Smart 8-Channel 16MP PoE NVR with Support for 16TB Storage

8 PoE Channels for Plug-and-Play Setup
Supports Up to 16MP Ultra HD Resolution
Expandable Storage Capacity Up to 16TB
Continuous 24/7 Recording Across Multiple Channels
4K HDMI and VGA Dual Video Outputs
Broad Compatibility with Reolink IP Cameras

Price range: RM999.00 through RM2,379.00

Addons

Storage

Clear

Reolink RLN8

RLN8 Video

4 Videos

Others Video

Disclaimer: The videos are intended for reference purposes only and are not guaranteed to be 100% accurate. Please refer to the actual product or contact us for verification.

Check it Out

Channel Capacity, PoE System Overview & Hardware Architecture

What type of NVR is the Reolink RLN8 and how many camera channels does it support?

A: The Reolink RLN8 is a compact, high-performance Network Video Recorder equipped with 8 built-in Power over Ethernet (PoE) ports. On updated hardware versions (Such as N7MB01), it supports up to 12 IP cameras in total (8 directly connected wired PoE cameras plus additional cameras added via a local network switch or router) for centralized 24/7 continuous recording, live monitoring, and unified device management.

How does the built-in 8-channel PoE system work?

A: The rear panel features 8 independent RJ45 PoE ports conforming to IEEE 802.3af/at standards. Each port delivers up to 25W of power, transmitting both high-definition digital video and electric power simultaneously over a single Cat5e, Cat6, or Cat7 Ethernet cable up to 100 meters (330 feet) without requiring separate power adapters for each camera.

Can the RLN8 connect to Reolink WiFi cameras and battery-powered cameras?

A: Yes. In addition to direct wired PoE cameras, the RLN8 can manage and record Reolink WiFi cameras (Such as E1 series, TrackMix WiFi, RLC-843WA, RLC-840WA, and Reolink Video Doorbells) connected through the same local WiFi router network. Compatible Reolink battery-powered cameras with updated firmware can also link to the system for motion-triggered event recording.

Does the RLN8 feature front-panel physical controls?

A: Depending on the production batch, some chassis revisions include front-panel directional navigation buttons, while others feature a sleek, minimalist front panel equipped with a Power LED, HDD Activity LED, and 1x USB 2.0 port. Complete system navigation is operated via the included USB optical mouse connected to the front or rear USB ports.

Can the RLN8 operate completely offline without an Internet connection?

A: Yes. The RLN8 functions seamlessly as an entirely offline, closed-circuit security system. You can connect your PoE cameras directly into the 8 rear ports, record 24/7 video directly to the installed internal SATA hard drive, and view live video feeds or playback on a locally connected HDMI or VGA monitor. An Internet connection is only required if you wish to receive mobile push notifications, email alerts, or access camera streams remotely via the Reolink App or Client.

Video Decoding, Display Output & Audio

What video resolutions and stream decoding limits are supported by the RLN8?

A: The RLN8 supports ultra-high-definition video stream input and decoding up to 16 Megapixels Ultra HD (7680x2160), 12MP (4096x3072 / 4512x2512), 4K 8MP (3840x2160), 5MP (2560x1920), 4MP (2560x1440), 3MP (2304x1296), 1080p Full HD, and 720p HD across both mainstream and substream profiles.

Which video compression codecs are supported by the NVR?

A: The system supports both advanced H.265 (HEVC) and standard H.264 video compression formats. This significantly optimizes hard drive storage consumption and conserves network bandwidth while preserving sharp detail and color accuracy in 4K, 12MP, and 16MP footage.

What video display monitor outputs and output resolutions are available?

A: The rear panel provides two local display outputs:

How many channels can be played back synchronously at the same time?

A: The RLN8 supports synchronous multi-channel playback of up to 4 camera channels simultaneously on a locally connected HDMI/VGA monitor or via the Reolink Client desktop software, allowing you to review synchronized incident footage from multiple angles.

Does the RLN8 support audio recording and local audio output?

A: Yes. The NVR records incoming digital audio streams from connected cameras equipped with built-in microphones. For local audio monitoring on an external amplified speaker or TV monitor, the rear panel includes 1 RCA audio output port. Two-way interactive talk can also be conducted remotely using the Reolink App and Client software.

Hard Drive Installation, Storage Expansion & Recording Modes

Does this standalone RLN8 include a pre-installed hard drive, and what is the maximum storage capacity?

A: In this standalone edition, hard drives are sold separately (No HDD is pre-installed). The RLN8 is equipped with 1 internal SATA interface supporting up to an 8TB 3.5-inch or 2.5-inch internal SATA hard drive, plus 1 external eSATA port on the rear panel supporting up to an 8TB external eSATA hard drive. This provides a maximum total storage capacity of up to 16TB (1x 8TB internal + 1x 8TB external). Surveillance-grade hard drives (Such as Western Digital Purple or Seagate SkyHawk) are strongly recommended for continuous 24/7 read/write reliability.

How do you install an internal SATA hard drive into the RLN8 chassis?

A:

Turn off the NVR using the rear rocker power switch and disconnect the power adapter.
Remove the screws securing the metal top cover and slide the chassis cover off.
Connect the SATA data cable and power cable from the NVR motherboard to your SATA hard drive.
Align the hard drive with the mounting holes on the bottom tray of the chassis and secure it from underneath using the supplied HDD mounting screws.
Reassemble the outer cover, tighten the screws, reconnect the power supply, and power on the unit.
On your connected monitor, navigate to Settings > Storage, select the newly detected drive, and click Format to initialize it for recording.

How does the external eSATA port work on the RLN8?

A: The rear panel features a dedicated eSATA interface. By connecting an external eSATA hard drive enclosure or eSATA storage drive (up to 8TB capacity) with its own dedicated power source, the NVR will recognize the drive as secondary storage, expanding the total system capacity up to 16TB.

What recording modes and schedules can be configured on each channel?

A: Each channel can be configured independently with three flexible recording modes:

What happens when the hard drive reaches full capacity?

A: By default, the RLN8 has automatic HDD Overwrite enabled. When storage reaches 100% capacity, the NVR automatically overwrites the oldest recorded video footage to accommodate new recordings seamlessly without interrupting surveillance or requiring manual file deletion.

Physical Ports, Power Specs & Hardware Interfaces

What physical ports and LED indicators are located on the RLN8?

A:

What are the power requirements and power consumption of the RLN8?

A: The RLN8 is powered by an included external DC 48V to 53V power adapter. The base power consumption of the NVR unit itself is under 10W (Excluding installed hard drives and PoE power output delivered to connected cameras).

What are the physical dimensions, weight, and operating environment parameters?

A:

Dimensions: 260 mm (Width) x 41 mm (Height) x 230 mm (Depth)
Weight: Approximately 1.4 kg (Chassis unit without installed hard drive)
Operating Temperature: -10 degrees Celsius to +45 degrees Celsius (14 degrees Fahrenheit to 113 degrees Fahrenheit)
Operating Humidity: 10% to 90% non-condensing

How do you back up or export video recordings locally?

A: Insert a FAT32 or NTFS formatted USB flash drive into the front or rear USB 2.0 port. Using the connected mouse and monitor interface, navigate to the Playback menu, select the camera channel, date, and time range, click the Backup/Download icon, and export the selected video clips directly as MP4 files.

How do you perform a factory reset on the RLN8?

A: You can restore factory defaults directly via the monitor interface by navigating to Settings > System > Maintenance > Restore Defaults. Alternatively, if locked out of the system, power off the unit, open the metal chassis, press and hold the internal reset button located on the motherboard while powering the unit back on, and hold for 10 seconds until the system reboots.

Camera Pairing, PoE Wiring & Ecosystem Compatibility

How do you connect and configure wired PoE cameras to the RLN8?

A:

Connect a standard Cat5e/Cat6/Cat7 Ethernet cable from the camera's RJ45 port directly into one of the 8 PoE ports on the rear of the NVR.
The NVR automatically supplies electric power and assigns a private IP address to the camera.
On your connected monitor, navigate to Settings > Channel > Channel Management and ensure Auto Add is enabled. The video feed will appear on the live preview screen within a few seconds.

Which Reolink camera models are compatible with the RLN8?

A: The RLN8 is compatible with the entire Reolink ecosystem, including 4K/12MP/16MP PoE models (Such as RLC-843A, RLC-833A, RLC-823S2, RLC-840A, Duo series, and TrackMix series), Reolink WiFi cameras (Such as RLC-843WA, RLC-840WA, and E1 series), and Reolink PoE/WiFi Video Doorbells.

How do dual-lens cameras consume channels on the RLN8?

A:

Does the RLN8 support third-party ONVIF cameras?

A: Yes. The RLN8 supports standard ONVIF Profile S/T/G third-party IP cameras connected over the local network for standard video streaming and continuous/motion recording. However, proprietary features such as smart AI detection categorization (Human, vehicle, animal filtering), two-way audio talk, siren triggers, and spotlight illumination controls are only guaranteed on native Reolink cameras.

Can PoE cameras connected directly to the RLN8 be accessed individually on a PC?

A: Cameras connected directly to the NVR's 8 PoE ports operate on an isolated internal subnet managed exclusively by the NVR. To access their standalone web interfaces or RTSP streams directly from a local PC on your home network, you can enable the "Virtual Host" feature in the NVR's network settings.

Network Configuration, Remote Access & Software Integration

How do you complete the initial setup wizard on a connected monitor?

A:

Power on the NVR and wait for the splash screen to boot.
Select your Language, Screen Resolution, Date Format, and Time Format, then click Next.
Configure Daylight Saving Time (DST) and time zone parameters, then click Next.
Create a secure administrator password, set up password security questions, and optionally enable screen auto-lock.
Name your NVR, format your installed SATA hard drive under the Storage menu, configure DHCP network settings, and click Finish.

How do you set up remote mobile access using the Reolink App?

A:

Connect the NVR's LAN port to your home or office Internet router using an Ethernet cable.
Open the Reolink App on your smartphone, tap the "+" icon in the top right corner, and scan the QR code located on the NVR chassis label or tap Input UID/IP and manually enter the 16-character UID.
Enter the administrator username (admin) and the password created during initial setup.
Tap "Access" to view and manage all connected camera channels remotely over cellular data or external WiFi.

Which client software, operating systems, and web browsers are supported?

A:

How many user accounts and simultaneous video streams does the RLN8 support?

A: The RLN8 supports up to 20 user accounts (1 administrator account and 19 standard user accounts) and up to 12 simultaneous remote video streams (2 mainstreams and 10 substreams).

What items are included in the standard retail package of the standalone RLN8?

A: The standalone retail package includes:

Reolink RLN8 (RLN8-410 / NVS8) 8-Channel PoE NVR
NVR Power Adapter (DC 48V-53V)
1-Meter HDMI Cable
USB Optical Mouse
1-Meter RJ45 Network Cable
Pack of Internal HDD Mounting Screws
SATA Data/Power Cable
Quick Start Guide
Operational Instructions
