Smart 5MP Dual-Band Wi-Fi Security Camera with Two-Way Audio
5MP Super HD Resolution for Clear Video
Dual-Band WiFi for Stable Wireless Connection
Smart Person, Vehicle, and Animal Detection
Infrared Night Vision Up to 100 Feet
Built-In Microphone for Clear Audio Recording
IP67 Weatherproof Rating for Outdoor Durability
RM389.00–RM1,139.00Price range: RM389.00 through RM1,139.00
Reolink RLC-510WA
RLC-510WA Video
5 Videos
Others Video
Disclaimer: The videos are intended for reference purposes only and are not guaranteed to be 100% accurate. Please refer to the actual product or contact us for verification.
What is the video resolution and image sensor specification of the Reolink RLC-510WA?
A: The Reolink RLC-510WA is built with a 1/2.7-inch CMOS image sensor that captures 5-Megapixel Super HD video resolution (2560 x 1920 pixels at 20 frames per second). This delivers high visual clarity and detailed image capture for residential and business monitoring.
What are the lens specifications and focal parameters for the camera?
A: The camera is equipped with a fixed f=4.0mm lens with an F2.0 aperture and an auto-switching IR-cut filter. The fixed focal length provides a wide, balanced viewing area for general surveillance.
What night vision capabilities does the RLC-510WA provide?
A: The camera features infrared night vision equipped with 18 high-performance IR LEDs (850nm, 14mil). It automatically switches between day and night modes via an auto IR-cut filter, delivering clear black-and-white video in complete darkness up to 30 meters (100 feet).
What are the physical dimensions, weight, and exterior build design of the camera?
A: The Reolink RLC-510WA features a bullet camera design encased in a durable aluminum metal body with two external Wi-Fi antennas. It measures 67mm in diameter by 186mm in length (2.64 inches x 7.32 inches) and weighs approximately 415 grams (0.91 lbs).
What weather resistance ratings and environmental limits apply to the RLC-510WA?
A: The camera possesses an IP67 weatherproof rating, offering full protection against dust ingress, heavy rain, and snow. It operates reliably in temperatures ranging from -10 degrees Celsius to 55 degrees Celsius (14 degrees Fahrenheit to 131 degrees Fahrenheit) with operating humidity levels between 20% and 85%.
Power, Dual-Band WiFi & Network Connectivity
How is the Reolink RLC-510WA powered?
A: The RLC-510WA is powered via a DC 12V 1A power adapter (Included in the package). The package also includes a 4.5-meter (14.7-foot) power extension cable to make outdoor outlet installation convenient. Power consumption is under 12W.
What wireless WiFi standards and frequencies does the RLC-510WA support?
A: The RLC-510WA features dual-band WiFi capability, supporting both 2.4GHz and 5GHz operating frequencies adhering to IEEE 802.11a/b/g/n/ac wireless standards with WPA/WPA2 security encryption. Equipped with 2T2R MIMO antennas, it ensures stronger network signals and faster data transmission speeds.
Does the Reolink RLC-510WA support Power over Ethernet (PoE)?
A: No. The RLC-510WA is a dedicated WiFi camera powered via a DC 12V power adapter. While it features an RJ45 Ethernet connection port for network transmission, it cannot be powered directly using PoE. For a PoE version of this camera model, consider the Reolink RLC-510A.
What connection ports are located on the camera's pigtail cable?
A: The trailing pigtail cable includes four primary components:
DC Power Port: For connecting the included 12V 1A DC power supply adapter.
Hardware Reset Button: For restoring default factory settings.
RJ45 Ethernet Connector: For initial network setup or optional wired network data connection.
Waterproof Lid Assembly: For sealing the RJ45 connection against outdoor weather and moisture.
Why does the camera include an RJ45 Ethernet port if it is a WiFi camera?
A: The RJ45 Ethernet port serves two main purposes: it allows for quick and reliable initial WiFi setup via the Reolink App, and it provides an optional wired Ethernet network connection if you prefer a wired network setup instead of wireless connection.
Smart AI Detection & Audio Capabilities
What smart AI detection features are built into the RLC-510WA?
A: The camera incorporates onboard AI processing capable of analyzing and distinguishing human, vehicle, and pet/animal shapes from general background motion. This local target processing filters out non-threatening movements (Such as swaying foliage or insects) to significantly minimize false alerts.
Does the camera support audio recording and two-way audio?
A: The camera includes a built-in microphone to capture ambient sound alongside video recordings (One-way audio listening). However, it does not feature an integrated speaker, so full two-way voice communication is not supported.
Does the camera feature white spotlights or an active audio siren deterrence?
A: No. The RLC-510WA relies on standard infrared night vision and does not feature built-in white spotlights or an active audio siren. For WiFi bullet cameras with spotlight deterrence, models like the RLC-511WA are available.
Does the RLC-510WA support smart home voice integration?
A: Yes. The camera is compatible with Google Assistant, allowing users to stream live camera feeds onto supported smart displays using simple voice commands.
How are security notifications delivered when motion or an event is detected?
A: When an alert event is triggered, the camera sends instant push notifications to your mobile phone via the Reolink App and dispatches email alerts attached with image snapshots or video clips.
Local Storage, Recording Modes & Video Bitrate
Where is the microSD card slot located and what maximum capacity is supported?
A: The camera contains an onboard microSD card slot supporting memory card capacities up to 512GB for local storage. The slot is located on the body assembly beneath a weather-sealed protective cover secured by screws.
What recording modes are supported on the RLC-510WA?
A: The camera supports three flexible operational recording modes:
Motion-Triggered Event Recording: Records video clips only when motion or AI smart targets (Person, vehicle, animal) are detected (Default setting).
Scheduled Recording: Records continuously during pre-configured hours configured within the app or client.
Continuous 24/7 Recording: Saves continuous video footage non-stop to a microSD card, off-site FTP server, or Reolink NVR.
What video compression formats, frame rates, and bitrates are used?
A: The camera supports H.264 and H.265 video compression formats:
Mainstream: Resolution of 2560 x 1920 at 2fps to 20fps (Default: 20fps) with bitrates configurable from 2048 Kbps to 5120 Kbps (Default: 3072 Kbps).
Substream: Configurable frame rates from 4fps to 15fps (Default: 10fps) with bitrates from 128 Kbps to 1024 Kbps (Default: 1024 Kbps).
Can I record video footage to an NVR, NAS, or FTP server?
A: Yes. The RLC-510WA supports recording to Reolink Network Video Recorders (NVRs), NAS systems, and off-site FTP servers utilizing standard protocols including ONVIF, RTSP, RTMP, and P2P.
How much footage can a 512GB microSD card hold?
A: At the default mainstream bitrate of 3072 Kbps, a 512GB microSD card can store approximately 280 to 360 hours of continuous 5MP video recording, or several months of motion-triggered event clips.
Initial Setup, Mounting & Maintenance
What items are included in the standard Reolink RLC-510WA box?
A: The standard package includes:
Reolink RLC-510WA Camera
Dual Antennas
DC 12V 1A Power Adapter
4.5-meter Power Extension Cable
1-meter Network Cable
Quick Start Guide
24/7 Surveillance Sticker
Mounting Template
Pack of Screws with Drywall Anchors
Waterproof Lid Kit
Hex Key Wrench
How do I perform initial setup using the Reolink App?
A:
Connect the camera to your router using the included 1-meter network cable and plug in the 12V DC power adapter.
Launch the Reolink App, tap the plus (+) icon in the top right corner, and scan the QR code on the camera body.
Create an administrator password and assign a name to your camera.
Select your local WiFi network (2.4GHz or 5GHz), enter the WiFi password, and save the settings.
Disconnect the Ethernet cable to switch to wireless operation.
How do I mount the bullet camera to a wall or ceiling surface?
A:
Apply the mounting template to the desired wall or ceiling location and drill holes.
Insert drywall anchors if mounting on drywall or masonry.
Pass the trailing pigtail cable through the cable notch on the mount base.
Secure the mount base to the surface using the provided screws.
Ensure the dual WiFi antennas are positioned vertically or horizontally for optimal wireless reception.
How do I adjust the camera's viewing angle after mounting?
A: Loosen the bracket adjustment screw counterclockwise using the included hex key wrench. Swivel and tilt the bullet camera body (Supports 360 degrees horizontal rotation and 90 degrees vertical tilt) to achieve your target viewing coverage, then tighten the screw clockwise to fix the camera securely in place.
How do I perform a hardware factory reset on the RLC-510WA?
A: Locate the reset button on the camera's pigtail cable assembly. Unscrew the protective cap, then press and hold the reset button for approximately 10 seconds while the camera is powered on until default factory settings are restored.
Software Compatibility, Protocols & Support
What mobile and desktop operating systems and web browsers support the RLC-510WA?
A:
Desktop Software: Windows PC and Mac OS (via Reolink Client).
Mobile Platforms: iOS and Android (via Reolink App).
Web Browsers: Microsoft Edge, Google Chrome, Mozilla Firefox, and Apple Safari.
How many simultaneous user accounts and video streams are permitted?
A:
User Accounts: Supports up to 20 user accounts (1 administrator account and 19 standard user accounts).
Video Streams: Supports up to 12 simultaneous video streams (10 substreams and 2 mainstreams).
What network protocols and security standards are supported?
Is a paid monthly subscription required to use smart AI detection or software features?
A: No. All core camera features—including smart person/vehicle/pet detection, local microSD storage, live streaming, push notifications, audio recording, and software access—are completely subscription-free.
What warranty and technical support service come with the Reolink RLC-510WA?
A: The camera includes a 2-year limited hardware warranty and access to official technical support through the online Reolink Help Center.
