Reolink TrackMix LTE

Smart 4G LTE Dual-Lens Battery Camera with Auto-Zoom Tracking

Dual-Lens Design for Simultaneous Dual Views
Auto-Tracking with Pan, Tilt, and Zoom
4G LTE Connectivity for Off-Grid Monitoring
Rechargeable Battery with Solar Panel Support
Smart Person, Vehicle, and Animal Detection
Color Night Vision with Built-In Spotlights

Price range: RM1,399.00 through RM2,057.00

Addons

Storage

Clear

Reolink TrackMix LTE

TrackMix LTE Video

7 Videos

Compare - Trackmix LTE vs TrackMix PoE vs TrackMix WiFi

Solar Panel Video

Others Video

Disclaimer: The videos are intended for reference purposes only and are not guaranteed to be 100% accurate. Please refer to the actual product or contact us for verification.

Check it Out

Dual-Lens Optics, 4K Video & 6× Hybrid Zoom

What lens configuration and video resolution does the Reolink TrackMix LTE feature?

A: The Reolink TrackMix LTE is engineered with a dual-lens optical system powered by a 1/3-inch CMOS image sensor. It combines a wide-angle lens (f=2.8mm, F1.6) and a telephoto lens to capture 4K Ultra HD video at up to 3840x2160 resolution (8.0 Megapixels) at 15 fps. The telephoto lens simultaneously captures a crisp closeup feed (1080p Full HD at 15 fps), delivering full situational awareness and target magnification on a single screen.

What is Dual-View Display and how does it work on the TrackMix LTE?

A: Dual-View Display presents two synchronized video streams on your screen at the same time:

Panoramic Overview: The wide-angle lens maintains an expansive view (108.4 degrees horizontal) to monitor the entire surrounding property.
Magnified Closeup: The telephoto lens tracks and displays a magnified, sharp closeup of moving subjects within the same frame. Both views can be reviewed side-by-side or in picture-in-picture mode via the Reolink App and Reolink Client software.

How does the 6× Hybrid Zoom operate?

A: The camera uses a 6× hybrid zoom system combining optical lens coordination and digital zoom algorithms. When tracking or zooming in on a target, the camera transitions between the wide-angle lens and the telephoto lens, applying digital enhancement to preserve crisp details such as license plates and facial contours without sacrificing clarity.

What is the Field of View (FOV) of each lens?

A:

What night vision modes are available on the TrackMix LTE?

A: The camera offers two high-clarity night vision modes:

Black-and-White Infrared (IR) Mode: Employs 2 high-power 850nm IR LEDs with an automatic IR-cut filter to illuminate nighttime scenes up to 30 meters (100 feet) in total darkness.
Full-Color Night Vision: Activates an integrated high-output spotlight (6500K color temperature, 450 lumens) upon motion detection or manual trigger, illuminating the scene to capture vivid, full-color surveillance footage.

PTZ Gimbal, Auto-Zoom Tracking & Presets

What are the pan and tilt rotation ranges of the TrackMix LTE?

A: The camera is equipped with a motorized pan/tilt gimbal base providing:

What is Auto-Zoom Tracking and how does it follow subjects?

A: Auto-Zoom Tracking leverages the camera's motorized gimbal and dual-lens array. When a classified target (person, vehicle, or animal) triggers the detection system, the motorized gimbal pans and tilts to keep the subject centered in the wide-angle panoramic view, while the telephoto lens automatically magnifies and tracks the subject in a synchronized closeup window.

What tracking styles can be configured in the camera settings?

A: You can choose between three tracking styles depending on your deployment area:

Digital Tracking: The mechanical camera body remains stationary while the telephoto view digitally zooms and tracks the moving subject within the fixed frame.
Digital Tracking First: The camera prioritizes digital closeup framing within its current field of view, panning mechanically only when the target approaches the screen edge.
Pan/Tilt Tracking First: The camera physically pans and tilts immediately to track the moving subject, ensuring both wide-angle and closeup views remain centered on the target.

How many preset points does the TrackMix LTE support?

A: The TrackMix LTE supports up to 32 user-defined preset positions and 1 customizable Guard Position. After completing an auto-tracking event or manual pan/tilt patrol, the camera automatically returns to its designated Guard Position to resume monitoring your primary area of interest.

Does the TrackMix LTE support continuous 24/7 automatic mechanical patrols?

A: No. Because the TrackMix LTE is powered by an internal rechargeable battery, continuous 24/7 mechanical patrolling is disabled to prevent rapid battery depletion. However, users can tap any of the 32 saved presets at any time to instantly swing the camera to pre-configured angles of interest.

Cellular 4G LTE Connectivity, SIM Cards & Data Plans

What mobile cellular networks and SIM card types are supported?

A: The TrackMix LTE operates completely untethered over 3G and 4G LTE cellular data networks without requiring WiFi. It uses a standard Nano SIM card supporting WCDMA and FDD/TDD LTE bands. Regional hardware versions are tailored for specific carrier frequency bands:

How do you prepare and activate the SIM card before inserting it?

A:

Activate the SIM card on your carrier's cellular data plan.
If the SIM card is locked with a PIN code, insert it into a smartphone first to disable the PIN lock before placing it in the camera.
Verify that the SIM card has an active data allowance and supports standard data browsing (do not use restricted smartphone-only plans or locked IoT profiles that block third-party hardware).

Where is the SIM card slot located and how is it installed?

A: The SIM card slot is located behind a weather-sealed metal hatch secured by screws on the side of the upper camera body.

Unscrew and remove the hatch cover using the included screwdriver.
Insert a SIM eject tool or needle into the hole beside the SIM tray and push gently to pop out the tray.
Place your active Nano SIM card into the tray with the gold contacts facing correctly, slide the tray firmly into the slot, and screw the sealed hatch cover back on tightly.

What do the camera's voice prompts and LED lights indicate during cellular network setup?

A:

Red LED Solid, then Turns Off: The camera is reading and registering the SIM card.
Flashing Blue LED, then Solid Blue: The camera has successfully negotiated a cellular data connection.
Voice Prompt "Network Connection Succeeded": The camera is online and ready to be bound to the Reolink App.
Voice Prompt "SIM Card Cannot Be Recognized": Check that the SIM card is inserted facing the proper direction and fully seated.
Voice Prompt "The SIM Card Is Locked with a PIN": Place the SIM into a smartphone and disable the PIN lock.
Voice Prompt "Not Registered on Network": Check carrier coverage, signal strength, or call your mobile operator to ensure the data line is active.

How much cellular data does the TrackMix LTE consume per month?

A: Data usage depends directly on live viewing duration, video streaming resolution, and motion trigger frequency:

Average Use: Under typical conditions (10 to 20 motion triggers daily and brief 2 to 3 minute live-view check-ins), monthly data consumption ranges between 1GB and 3GB.
Heavy Remote Viewing: Frequent live streaming in full 4K "Clear" mode consumes approximately 1GB per hour, whereas streaming in "Fluent" (substream) mode consumes approximately 150MB to 250MB per hour.

Battery Power, Solar Integration & Charging Logic

What is the battery capacity and electrical specification of the TrackMix LTE?

A: The camera is equipped with an integrated high-capacity 5100mAh (7.2V / 36.72Wh) rechargeable lithium-ion battery pack. It is recharged via an outdoor-sealed USB Type-C power port using a standard DC 5V / 2A charger (supports USB-A to USB-C charging cables).

How long does the battery last on a single charge?

A: Under average residential or remote property conditions (10 to 20 motion-triggered recordings and occasional live viewing daily), a full charge typically lasts 1 to 4 weeks. For zero-maintenance, self-sustaining continuous operation, connecting a Reolink Solar Panel is strongly recommended.

Which solar panels are compatible with the TrackMix LTE?

A: The camera connects natively to Reolink solar panels via its weather-sealed USB-C lead:

Reolink Solar Panel 2 (6W): The standard solution providing ample trickle charge under 2 to 3 hours of daily direct sunlight.
Reolink Solar Panel 2S (6W with Built-in Battery): Adds an external 5900mAh buffer battery that bypasses low-temperature lithium charging thresholds down to -10 degrees Celsius.
Reolink Solar Panel 3 (12W): Delivers high-current output optimized for high-traffic zones, farms, construction sites, and shorter winter daylight hours.

Why does the camera refuse to recharge below freezing (0°C / 32°F)?

A: Standard lithium battery chemistries cannot be safely charged below 0 degrees Celsius (32 degrees Fahrenheit) without causing irreversible metallic lithium plating on the anode, which leads to permanent capacity loss and internal short circuits. The camera's built-in Battery Management System (BMS) automatically halts charging below freezing and resumes automatically when temperatures rise back into the safe charging range (0 degrees Celsius to 45 degrees Celsius).

Can the TrackMix LTE record continuously 24/7 like a wired security camera?

A: No. Battery and cellular-powered cameras are engineered specifically for event-driven wake-and-record operation. Constant 24/7 video streaming and recording over cellular networks would deplete the internal battery pack and exhaust data allowances within 24 to 48 hours. Instead, the camera stays in ultra-low-power standby, waking within fractions of a second upon PIR motion detection or remote user app access.

PIR Detection, Smart Edge AI & Active Deterrence

How does the passive infrared (PIR) detection sensor work?

A: The TrackMix LTE features an integrated wide-angle PIR sensor with a 100-degree horizontal sensing angle and an adjustable detection range up to 11 meters (36 feet). The PIR sensor detects shifts in thermal infrared radiation emitted by people, animals, and warm vehicle engines, waking the camera instantly from low-power sleep mode.

Which smart AI target classification categories are supported?

A: Once awakened by the PIR sensor, on-device neural algorithms analyze subject contours in real time to categorize detections into:

What active deterrence features are built into the TrackMix LTE?

A: The camera incorporates two automated active deterrence tools:

Does the TrackMix LTE support two-way interactive voice communication?

A: Yes. The camera is equipped with a built-in noise-canceling microphone and a high-output loudspeaker. This enables real-time full-duplex two-way audio conversations with delivery couriers, workers, visitors, or trespassers directly through the Reolink App or Client over the cellular link.

What alert notifications occur when motion is detected?

A: When an alarm rule is triggered, the camera can execute:

Storage Options, Mounting Methods & Hardware Maintenance

What local and remote storage destinations are supported?

A:

Onboard MicroSD Card: Supports local recording via an onboard waterproof MicroSD card slot accommodating cards up to 128GB (FAT32 format, Class 10 or higher recommended).
Reolink Cloud: Encrypted cloud backup storage available in selected geographic regions and data plans.
Note: Because this is an event-driven cellular camera, standard third-party ONVIF, RTSP, FTP, and continuous NVR streaming are not supported.

Where are the hardware controls and MicroSD card slot located?

A:

MicroSD Card Slot: Located on the underside of the rotating sphere beneath a weather-sealed silicone rubber hatch.
Hardware Power Switch: Located on the side of the camera body next to the SIM card slot under the weather-sealed hatch.
Hardware Reset Button: Located beside the SIM card slot (press and hold with a pin or needle for 10 seconds while powered on to restore factory defaults).

How is the TrackMix LTE mounted to walls, ceilings, or trees?

A: The camera includes a multi-purpose mounting bracket supporting three mounting methods:

Wall Mounting: Secure the vertical plate of the bracket to an exterior wall using the provided screws and drywall anchors.
Ceiling / Soffit Mounting: Fasten the top horizontal plate of the bracket to an overhead ceiling, beam, or eaves soffit.
Tree / Pole Mounting (Loop Strap): Fasten the mounting plate to the mount base with screws, thread the included heavy-duty loop strap through the plate, and cinch it firmly around a tree trunk, utility pole, or fence post.

What is the weatherproof rating and working temperature range?

A:

What items are included in the standard retail package, and what warranty coverage is provided?

A: Package Contents:

Reolink TrackMix LTE Camera
Multi-Purpose Mounting Bracket
Mounting Plate
Loop Strap (Tree/Pole Mount)
USB-C Charging Cable
Mounting Hole Template
Pack of Screws
Wall Anchors
24-Hour Video Surveillance Warning Sticker
Quick Start Guide

A: Warranty:
