Reolink RP-PN8

Professional 12-Channel PoE NVR with AI Video Search & Heat Mapping

8 PoE Channels for Plug-and-Play Setup
Supports Up to 16MP Ultra HD Resolution
Expandable Storage Capacity Up to 16TB
Continuous 24/7 Recording Across Multiple Channels
4K HDMI and VGA Dual Video Outputs
Broad Compatibility with Reolink IP Cameras

Price range: RM1,299.00 through RM2,679.00

Addons

Storage

Clear

Reolink RP-PN8

RP-PN8 Video

7 Videos

Professional Series Video

Others Video

Disclaimer: The videos are intended for reference purposes only and are not guaranteed to be 100% accurate. Please refer to the actual product or contact us for verification.

Check it Out

Channel Capacity, PoE Architecture & Hardware Design

What is the Reolink Professional Series RP-PN8 and how many total camera channels does it support?

A: The Reolink RP-PN8 is an enterprise-grade 12-channel Power over Ethernet (PoE) Network Video Recorder (NVR) designed for 24/7 continuous surveillance recording and centralized device management. It features 8 built-in PoE ports and supports up to 12 IP cameras in total: up to 8 wired PoE or plug-in powered WiFi cameras plus 4 battery-powered WiFi cameras, or up to 12 battery-powered WiFi cameras simultaneously.

How does the built-in 8-channel PoE system operate?

A: The rear panel features 8 dedicated 10/100 Mbps RJ45 PoE ports conforming to IEEE 802.3af/at standards. Each port can deliver up to 25W of power, transmitting ultra-high-definition video and electric power over a single Cat5e, Cat6, or Cat7 Ethernet cable up to 100 meters (330 feet) without requiring separate power adapters for each camera.

Which camera types and maximum resolutions are supported on each channel?

A: The RP-PN8 supports the entire Reolink camera ecosystem, including wired PoE cameras, plug-in WiFi cameras, Reolink Video Doorbells, and compatible Reolink battery-powered WiFi cameras. Each channel supports ultra-high-definition video stream inputs up to 16 Megapixels (7680x2160). Standalone 4G cellular cameras lacking local WiFi bridging are excluded.

What physical ports, controls, and LED indicators are found on the RP-PN8 chassis?

A:

Front Panel: Power LED indicator (Solid green when powered on), HDD Activity LED indicator (Flashing red during active read/write operations), and 1x USB 2.0 port for mouse or flash drive connection.
Rear Panel: Power On/Off rocker switch, DC 52V Power Input port, 1x RCA Audio Output port, 1x eSATA port, 1x VGA monitor port, 1x HDMI monitor port, 1x RJ45 10/100/1000 Mbps Gigabit LAN/WAN uplink port, 1x USB 2.0 port, and 8x RJ45 10/100 Mbps PoE camera ports.

Can the RP-PN8 operate completely offline without an Internet connection?

A: Yes. The RP-PN8 functions seamlessly as an entirely offline, closed-circuit security system. You can connect PoE cameras directly to the rear ports, record continuous 24/7 footage to an installed internal SATA hard drive, and view live video feeds or playbacks on a locally connected HDMI or VGA monitor. An Internet connection is only required for remote mobile viewing, push notifications, email alerts, or firmware updates.

Video Decoding, Display Output & Audio Specs

What video decoding resolutions and throughput bandwidth are supported?

A: The RP-PN8 delivers 240 Mbps incoming bandwidth and 240 Mbps outgoing bandwidth. It decodes ultra-high-definition camera streams across resolutions including 16MP (7680x2160), 12MP (4512x2512 / 4096x3072), 8MP 4K (3840x2160), 5MP (2560x1920), 4MP (2560x1440), 3MP (2304x1296), 1080p Full HD, and 720p HD.

Which video compression codecs are supported by the NVR?

A: The system supports dual video compression standards: high-efficiency H.265 (HEVC) and standard H.264. H.265 significantly optimizes hard drive storage retention and conserves network streaming bandwidth while preserving pristine detail and color accuracy in 4K, 12MP, and 16MP surveillance footage.

What video monitor outputs and display resolutions are available?

A: The rear panel provides two local display monitor outputs:

How many channels can be played back synchronously at the same time?

A: The RP-PN8 supports synchronous multi-channel playback of 1 to 4 channels simultaneously on a locally connected monitor or via the Reolink Client software. When reviewing video recorded at 8MP (4K) or higher resolutions, the system supports 1-channel synchronous playback at full resolution to guarantee smooth decoding.

Does the RP-PN8 support audio recording and local audio output?

A: Yes. The NVR records incoming digital audio streams from connected cameras equipped with built-in microphones. For local audio monitoring on an amplified speaker, audio receiver, or external monitor, the rear panel includes 1 RCA audio output port. Interactive two-way talk can also be conducted remotely using the Reolink App and Client software.

Storage Expansion, File Encryption & Recording Schedules

What is the maximum storage capacity of the RP-PN8 and what drive configurations are supported?

A: In this standalone edition, hard drives are sold separately (No HDD is pre-installed in the chassis). The RP-PN8 supports a massive enterprise storage capacity of up to 32TB in total:

How do you install or replace an internal SATA hard drive in the RP-PN8?

A:

Turn off the NVR using the rear rocker power switch and disconnect the DC 52V power adapter.
Remove the screws securing the top metal cover and slide the chassis cover off.
Connect the SATA data cable and power cable from the NVR motherboard to your SATA hard drive.
Align the hard drive with the mounting holes on the bottom tray of the chassis and secure it firmly from underneath using the supplied HDD mounting screws.
Reassemble the outer cover, tighten the screws, reconnect the power supply, and turn on the rocker power switch.
On your connected monitor, navigate to Settings > Storage, select the newly detected drive, and click Format to initialize it for recording.

What is the File Encryption feature on the RP-PN8?

A: The rear panel features an enterprise eSATA interface. By connecting an external eSATA hard drive enclosure or eSATA storage drive (Up to 16TB capacity) with its own dedicated power source, the NVR will recognize the drive as secondary storage, expanding the total system capacity up to 32TB (16TB internal + 16TB external).

What recording modes and schedules can be configured on each channel?

A: The RP-PN8 includes an advanced on-device File Encryption feature. When enabled in the Storage management settings, recorded surveillance video files are encrypted directly on the disk. This ensures that even if the hard drive is physically removed or stolen from the premises, the recorded video data cannot be accessed or played back on unauthorized computers.

What happens when the installed hard drive reaches 100% capacity?

A: By default, the RP-PN8 has automatic HDD Overwrite enabled. When storage reaches full capacity, the NVR automatically writes over the oldest recorded video files to accommodate new recordings seamlessly without interrupting surveillance or requiring manual file maintenance.

AI Video Search, Heat Map & Advanced Analytics

How does the AI Video Search feature work on the RP-PN8?

A: AI Video Search enables natural language querying to locate specific recorded video clips rapidly without manually scanning through hours of footage. Users can type descriptive phrases such as "white van" or "person wearing a hat" via a virtual or connected physical keyboard. Alternatively, users can use the structured click-to-select panel to pick attributes (e.g., Top: T-shirt, Color: Red). All searches are performed locally on the NVR hardware, protecting data privacy with zero cloud subscription fees.

What is the Heat Map function and where is it used?

A: The Heat Map function visually tracks and displays foot traffic patterns by analyzing movement density and dwell times across monitored spaces. Commonly utilized in retail stores, supermarkets, shopping malls, and commercial lobbies, it generates a clear color-coded map highlighting high-traffic corridors and congregating spots to optimize facility layout and customer flow.

Which smart target classification categories can the RP-PN8 manage?

A: When connected to compatible Reolink AI cameras, the RP-PN8 categorizes and filters alerts based on:

Person Detection
Motor Vehicle Detection
Non-Motorized Vehicle Detection (Bicycles, carts, scooters)
Animal / Pet Detection
Package Detection
General Motion Detection

What Perimeter Protection analytics are supported by the RP-PN8 system?

A: When paired with Reolink Professional Series cameras, the RP-PN8 supports commercial perimeter analytics:

Line Crossing Alert: Triggers an alarm when a target crosses a virtual line drawn across an entry gate, driveway, or boundary.
Zone Intrusion Alert: Detects when a target enters a designated restricted perimeter zone.
Zone Loitering Alert: Flags an alert when a target lingers within a defined zone beyond a user-configured duration threshold.

What abnormal smart event detections are available?

A: The system supports edge-driven abnormal event detection algorithms (Beta), including:

Network Topology, Camera Pairing & Compatibility

What network ports and bandwidth architecture does the RP-PN8 feature?

A: The RP-PN8 features a dual-network layout:

How do you connect and configure wired PoE cameras and WiFi cameras?

A:

Wired PoE Cameras: Connect an Ethernet cable from the camera directly into one of the 8 rear PoE ports. The NVR automatically powers the camera and assigns a private IP address.
WiFi Cameras: Connect the WiFi camera to the same local router network as the NVR's LAN port.
On the monitor interface, go to Settings > Channel > Channel Management and ensure Auto Add is enabled. The camera feeds will appear automatically on the live preview screen.

How do dual-lens panoramic cameras (e.g., RP-PCT16MD, RP-PCT8MD) consume channels on the RP-PN8?

A: Reolink dual-lens panoramic cameras perform dual-sensor image stitching directly on the camera hardware before transmitting the video. As a result, the camera outputs a single seamless 180-degree panoramic stream, consuming only 1 channel on the RP-PN8.

Does the RP-PN8 support third-party ONVIF cameras?

A: Yes. The RP-PN8 supports standard ONVIF Profile S/T/G third-party IP cameras connected over the local network for standard video streaming, manual recording, and motion recording. However, proprietary features such as smart AI classification, AI Video Search, two-way audio talk, siren triggers, and spotlight controls are only guaranteed on native Reolink cameras.

Can PoE cameras connected directly to the NVR be accessed individually on a PC?

A: Cameras connected directly to the NVR's 8 PoE ports operate on an isolated internal subnet managed exclusively by the NVR. To access their standalone web interfaces or RTSP streams directly from a local PC on your home network, you can enable the "Virtual Host" feature in the NVR's advanced network settings.

System Configuration, Remote Software & Package Contents

What are the physical dimensions, weight, and operating environment parameters of the RP-PN8?

A:

Dimensions: 255 mm (Width) x 50 mm (Height) x 211 mm (Depth)
Weight: Approximately 1.4 kg (Chassis without installed hard drive)
Operating Temperature: -10 degrees Celsius to +45 degrees Celsius (14 degrees Fahrenheit to 113 degrees Fahrenheit)
Operating Humidity: 10% to 90% non-condensing

What power supply does the RP-PN8 require and what is its power consumption?

A: The RP-PN8 is powered by an included high-efficiency external DC 52V / 2.3A power adapter. The base power consumption of the NVR unit itself is under 10W (Excluding installed hard drives and PoE power output delivered to connected cameras).

How do you set up remote mobile access using the Reolink App?

A:

Connect the NVR's Gigabit LAN port to your home or office Internet router using an Ethernet cable.
Open the Reolink App on your smartphone, tap the "+" icon in the top right corner, and scan the QR code located on the NVR chassis label or tap Input UID/IP to manually enter the 16-character UID.
Enter the administrator username (admin) and the password created during initial setup.
Tap "Access" to view and manage all 12 connected camera channels remotely over cellular data or external WiFi.

How do you back up or export video recordings locally?

A: Insert a FAT32 or NTFS formatted USB flash drive into the front or rear USB 2.0 port. On the monitor interface, navigate to the Playback menu, select the camera channel, date, and time range, click the Download/Backup icon, and export the selected video clips directly as MP4 files.

What items are included in the standard retail package, and what is the warranty coverage?

A: Package Contents:

Reolink Professional Series RP-PN8 12-Channel PoE NVR
NVR Power Adapter (DC 52V 2.3A)
1-Meter HDMI Cable
USB Optical Mouse
1-Meter RJ45 Network Cable
Quick Start Guide
Operational Instructions
Internal SATA HDD Mounting Screws
SATA Connection Cable

A: Warranty:
